Sunmate SMS 10.2KVA 48V Hybrid With Inbuilt 160A MPPT Solar Inverter And Charger (10KVA) Sunmate Solar
Inhouse product
Reviews & Ratings
This robust SMS inverter provides a staggering 10200W of continuous backup power, ensuring your entire home remains operational during unexpected power outages. Additionally, it boasts a built-in solar charger, allowing you to harness the sun’s clean energy to potentially reduce dependence on the grid and potentially lower your electricity bills.
Key Features
Operating Temperature Range: -10°C to +50°C
• Model Number: SMS-10.2KW-48V
• Made in China
• PV Input (Solar Input):
• Nominal Operating Voltage: 240Vdc
• Maximum PV Voltage (Vmax PV): 500Vdc
• PV Input Voltage Range: 60Vdc to 450Vdc
• Maximum Input Current (Imax PV): 27A
• Full Load MPPT Range: 240Vdc to 450Vdc
• Rated Power: 10200W
• Maximum Solar Charging Current: 160A
Grid/AC Output (Utility Output):
• Nominal Output Voltage: Selectable 220Vac, 230Vac, or 240Vac
• Feed-in Grid Voltage Range: 195 Vac to 253 Vac
• Feed-in Grid Frequency Range: 49Hz to 51Hz ± 1Hz
• Nominal Output Current: 15.7A
• Power Factor Range: Greater than 0.99
• Maximum Conversion Efficiency (DC/AC): 97%
• Nominal Operating Frequency: 50Hz or 60Hz (selectable)
• AC Input (Grid Charging):
• Nominal Operating Voltage: 230Vac
• Maximum Input Current: 50A
• Nominal Operating Frequency: 50Hz or 60Hz (selectable)
• Surge Power: 20400VA
• Maximum AC Charging Current: 100A
• Battery Voltage Range: 40Vdc to 63Vdc
• Maximum Battery Current: 150A
Specifications
- Product Line: Hybrid inverter
- Model: SMS-10.2KW-48V
- Production Country: China
- Size (L x W x H cm): 5x10x15
- Weight (kg): 25
- Certifications: Eco-Friendly
- Colour: Gold & Black
- Main Material: Copper
