Sunmate Sms 6.5KVA 48V Hybrid Solar inverter
Inhouse product
Reviews & Ratings
The SMS 6.5KVA 48V Hybrid Inverter delivers 6500W of power, ensuring your appliances stay on. It also features a built-in solar charger and can handle up to 120A of solar input, allowing you to harness clean energy from the sun and potentially reduce your electricity bills. Enjoy peace of mind and energy independence with this hybrid solution!
Key Features
Operating Temperature Range: -10°C to +50°C
• Model Number: SMS-6.5KW-48V
• Made in China
• PV Input (Solar Input):
• Nominal Operating Voltage: 240Vdc
• Maximum PV Voltage (Vmax PV): 500Vdc
• PV Input Voltage Range: 60Vdc to 450Vdc
• Maximum Input Current (Imax PV): 27A
• Full Load MPPT Range: 240Vdc to 450Vdc
• Rated Power: 6500W
• Maximum Solar Charging Current: 120A
Grid/AC Output (Utility Output):
• Nominal Output Voltage: Selectable 220Vac, 230Vac, or 240Vac
• Feed-in Grid Voltage Range: 195 Vac to 253 Vac
• Feed-in Grid Frequency Range: 49Hz to 51Hz ± 1Hz
• Nominal Output Current: 15.7A
• Power Factor Range: Greater than 0.99
• Maximum Conversion Efficiency (DC/AC): 97%
• Nominal Operating Frequency: 50Hz or 60Hz (selectable)
• AC Input (Grid Charging):
• Nominal Operating Voltage: 230Vac
• Maximum Input Current: 30A
• Nominal Operating Frequency: 50Hz or 60Hz (selectable)
• Surge Power: 7200VA
• Maximum AC Charging Current: 100A
• Battery Voltage Range: 20Vdc to 33Vdc
• Maximum Battery Current: 150A
